The skid-based 6 Ton ColPro ECU provides a powerful 72,000 BTU/H (21.1 kW) of cooling using ozone-friendly R-407C refrigerant and is equipped with 16” (40.5 cm) supply and return air ducts* and a five position selector switch.

Key Features:

  • Environmentally acceptable R-407C refrigerant
  • Hot gas by-pass
  • 2,200 CFM (3738 m3/h)
  • 16″ (40.6 cm) supply and return air ducts*
  • Formed aluminum enclosure
  • CARC paint system
  • Designed for ease of transport – 16 units fit on a single 463L pallet (4 stacks x 4 high)**
  • ECU integrates with HDT fan filter assembly (power / ducts)*
  • CBRN compatible
  • Protection factor is 400 times better than required levels (Test)
  • Meets military transport requirements (MIL-STD- 810F)
  • Handheld remote control
  • Six-position selector switch with thermostat to monitor return air
    temperature: REMOTE-HEAT-OFF-VENT-COOL-AUTO
  • Receptacles to power air filtration unit and filtered air connections are included

* Turf Cart and ducts sold separately
** Without turf wheel cart installed

Datasheets

6 Ton ColPro ECU
